新型不锈钢带退伙后氧化皮清理及应力强化工艺
可利用一种连续通过式抛丸强化设备对退伙不锈钢带进行连续在线抛丸清理,让高速弹丸冲击不锈钢带的上下表面,一般采用上下两个表面根据清理速度不同各布置2-8个抛丸器。一般包括退火后预校平,抛丸清理,清扫,校平,收卷。
钢带抛丸机设备技术规范
Steel belt surface shot blast machine technology standard
1.钢带抛丸机主要用于去除钢带外表面的锈蚀及氧化皮,获得一定粗糙度的金属本色表面。
Steel steel belt shot blast machine serve as cleaning away the scale and rust,which can get the primitive surface with certain rough degree.
2.被清工件的主要参数 :
Parameters of cleaned workpiece
2.1.长度(mm) :不限
Length(mm): no limitted
2.2.钢带宽度(mm):1500mm
width of the steel belt :1500mm
2.3.钢带厚度(mm):2-30
Thickness of the steel belt 2-30
3.技术特征:
Technology Features:
3.1.具有一次性可以同时清理1根钢带功能。
It can clean the 1 steel steel belt at the same time .
3.2.清理速度范围:10--60m/min
Range of cleaning speed: 10-60 m/min
3.3.抛丸器抛丸量:≥1200kg/minx16
Shot quantity of the impeller unit: ≥1200 kg/minx16
3.4.抛丸器功率:≥90kWx16
Power of the impeller unit: ≥90kWx16
3.5 抛丸器数量:16台
Quantity of the impeller unit: 16 sets.
3.6 提升机提升量:≥360 t/hx4
Quantity of the bucket elevator: ≥360 t/hx4
3.7 提升速度:>1.6m/s
Lift speed: >1.6m/s
3.8 提升机功率 :≥22 kWx4
Power of the bucket elevator: ≥22 kWx4
3.9 分离器分离量 :≥360 t/h
Seperating quantity of bucket elevator: ≥360 t/h
3.10 分离区风速:4,000-5,000mm/s
Air speed in the seperative zone: 4,000-5,000mm/s
3.11 输送器输送量:≥360t/hx4
Conveying quantity of the conveyor: ≥3600t/hx4
3.12 输送器功率 :11 kWx4
Power of the conveyor:11 kWx4
3.13 总通风量 :15000 m3/hx4
Total air quantity: 15000 m3/hx4
3.14 总功率:~480*4kW
Total power: ~480*4kW
各功能部件分布:
